Piuma UP3 alternating-cycle anti-decubitus kit – Nylon+PVC mattress – H 20.3 cm, with 20 interchangeable elements and compressor with regulation

Indicated for the prevention of bedsores up to STAGE IV. The first four elements have static operation with pillow function for the head; the remaining part is divided into two sections with alternating two-way operation; complete with padded cover in biocompatible, waterproof and breathable nylon/PU, tested according to European fire reaction regulations, with a zip on all four sides for easy removal and cleaning. The mattress is attached to the bed with the straps provided and has cable eyelets. The height of the elements allows the mattress to be used without an additional mattress. The elements are manufactured using the CELL-ON-CELL technique, which divides the section into two individual modules, with the lower one remaining constantly inflated to avoid an excessive BOTTOM-OUT (sinking) effect and to ensure safety in the event of a power failure. The compressor has manual pressure regulation, a visual and acoustic low-pressure alarm and interchangeable air filter. The STATIC function blocks the alternating system and turns it into a normal mattress. Mattress/compressor connection through rapid connectors with closure, usable to transport the patient.

Description

Compressor technical specifications (LAR711)

– Measurements: L:300 mm x D:135 mm x H:110 mm
– Power 220V / 50 Hz
– Pressure supplied 55~120mmHg
– Power cable 5 m
– Air outlet 7.5/8.5LPM
– Cycle time 12 min
– Fuse T1A 250V
– Noise level 30-35 dB

Mattress technical specifications (LAR403)

– Measurements when operating: L:2000 mm x D:860 mm x H:210 mm
– Material: Nylon+PVC
– Height of inflated element: 20.3 cm
– Number of elements 20 (of which 8 micro-perforated)
– CPR valve Deflation time around 15 sec.
– Capacity: 200 kg
Optional accessories available:
